Cisco Catalyst 3560-X User Manual

1-27
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Implementing IPv6 Multicast
Implementing IPv6 Multicast
Beginning in privileged EXEC mode, follow these steps:
Configuring Static Mroutes
Static multicast routes (mroutes) in IPv6 can be implemented as an extension of IPv6 static routes. You
can configure your switch to use a static route for unicast routing only, to use a static multicast route for
multicast RPF selection only, or to use a static route for both unicast routing and multicast RPF selection.
Beginning in privileged EXEC mode, follow these steps:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ipv6 mld [vrf vrf-name] ssm-map enable
Example:
Switch(config)# ipv6 mld ssm-map enable
Enables the SSM mapping feature for groups in the configured
SSM range.
Step 3
no ipv6 mld [vrf vrf-name] ssm-map query dns
Example:
Switch(config)# no ipv6 mld ssm-map query
dns
Disables DNS-based SSM mapping.
Step 4
ipv6 mld [vrf vrf-name] ssm-map static
access-list source-address
Example:
Switch(config)# ipv6 mld ssm-map static
SSM_MAP_ACL_2 2001:DB8:1::1
Configures static SSM mappings.
Step 5
exit
Example:
Switch(config-if)# exit
Exits global configuration mode, and returns the switch to
privileged EXEC mode.
Step 6
show ipv6 mld [vrf vrf-name] ssm-map
[source-address]
Example:
Switch# show ipv6 mld ssm-map
Displays SSM mapping information.
Step 7
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ipv6 route ipv6-prefix / prefix-length
ipv6-address | interface-type interface-number
ipv6-address]} [administrative-distance]
[administrative-multicast-distance | unicast|
multicast] [tag tag
Example:
Switch(config)# ipv6 route 2001:DB8::/64
6::6 100
Establishes static IPv6 routes. The example shows a static route
used for both unicast routing and multicast RPF selection.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
