1-74
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring QoS
Configuring Standard QoS
Beginning in privileged EXEC mode, follow these steps to modify the CoS-to-DSCP map. This
procedure is optional.
To return to the default map, use the no mls qos cos-dscp global configuration command.
This example shows how to modify and display the CoS-to-DSCP map:
Switch(config)# mls qos map cos-dscp 10 15 20 25 30 35 40 45
Switch(config)# end
Switch# show mls qos maps cos-dscp
Cos-dscp map:
cos: 0 1 2 3 4 5 6 7
--------------------------------
dscp: 10 15 20 25 30 35 40 45
Configuring the IP-Precedence-to-DSCP Map
You use the IP-precedence-to-DSCP map to map IP precedence values in incoming packets to a DSCP
value that QoS uses internally to represent the priority of the traffic.
Table 1-13 shows the default IP-precedence-to-DSCP map:
If these values are not appropriate for your network, you need to modify them.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
mls qos map cos-dscp dscp1...dscp8 Modify the CoS-to-DSCP map.
For dscp1...dscp8, enter eight DSCP values that correspond to CoS values
0 to 7. Separate each DSCP value with a space.
The DSCP range is 0 to 63.
Step 3
end Return to privileged EXEC mode.
Step 4
show mls qos maps cos-dscp Verify your entries.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.
Table 1-13 Default IP-Precedence-to-DSCP Map
IP Precedence Value DSCP Value
00
18
216
324
432
540
648
756

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
