Chapter 1 General Troubleshooting
1.12.3 OC-N Card Transmit and Receive Levels
Table 1-6 Optical Card Transmit and Receive Levels
Card
Transmit Receive
Minimum Maximum Minimum Maximum
OC3 IR 4/STM1 SH 1310 –15 dBm –8 dBm –28 dBm –8 dBm
OC3IR/STM1SH 1310-8 –15 dBm –8 dBm –28 dBm –8 dBm
OC12 IR/STM4 SH 1310 –15 dBm –8 dBm –28 dBm –8 dBm
OC12 LR/STM4 LH 1310 –3 dBm +2 dBm –28 dBm –8 dBm
OC12 LR/STM4 LH 1550 –3 dBm +2 dBm –28 dBm –8 dBm
OC12 IR/STM4 SH 1310-4 –15 dBm –8 dBm –30 dBm –8 dBm
OC48 IR 1310 –5 dBm 0 dBm –18 dBm 0 dBm
OC48 LR 1550 –2 dBm +3 dBm –28 dBm –8 dBm
OC48 IR/STM16 SH AS 1310 –5 dBm 0 dBm –18 dBm 0 dBm
OC48 LR/STM16 LH AS 1550 –2 dBm +3 dBm –28 dBm –8 dBm
OC48 ELR/STM16 EH 100 GHz –2 dBm 0 dBm –27 dBm at
1E-12 BER
–9 dBm
OC48 ELR/STM16 EH 200 GHz –2 dBm 0 dBm –28 dBm –8 dBm
OC192 SR/STM64 IO 1310 –6 dBm –1 dBm –11 dBm –1 dBm
OC192 IR/STM64 SH 1550 –1 dBm +2 dBm –14 dBm –1 dBm
OC192 LR/STM64 LH 1550 +7 dBm +10 dBm –19 dBm –10 dBm
OC192 LR/STM64 LH ITU 15xx.xx +3 dBm +6 dBm –22 dBm –9 dBm
15454_MRC-12 (ONS-SI-2G-S1) –10 dBm –3 dBm –18 dBm –3 dBm
15454_MRC-12 (ONS-SI-2G-I1) –5 dBm 0 dBm –18 dBm 0 dBm
15454_MRC-12 (ONS-SI-2G-L1) –2 dBm 3 dBm –27 dBm –9 dBm
15454_MRC-12 (ONS-SI-2G-L2) –2 dBm 3 dBm –28 dBm –9 dBm
15454_MRC-12 (ONS-SC-2G-30.3
through ONS-SC-2G-60.6)
0 dBm 4 dBm –28 dBm –9 dBm
15454_MRC-12 (ONS-SI-622-I1) –15 dBm –8 dBm –28 dBm –8 dBm
15454_MRC-12 (ONS-SI-622-L1) –3 dBm 2 dBm –28 dBm –8 dBm
15454_MRC-12 (ONS-SI-622-L2) –3 dBm 2 dBm –28 dBm –8 dBm
15454_MRC-12
(ONS-SE-622-1470 through
ONS-SE-622-1610)
0 dBm 5 dBm –28 dBm –3 dBm
15454_MRC-12 (ONS-SI-155-I1) –15 dBm –8 dBm –30 dBm –8 dBm
15454_MRC-12 (ONS-SI-155-L1) –5 dBm 0 dBm –34 dBm –10 dBm
15454_MRC-12 (ONS-SI-155-L2) –5 dBm 0 dBm –34 dBm –10 dBm
15454_MRC-12
(ONS_SE-155-1470 through
ONS-SE-155-1610)
0 dBm 5 dBm –34 dBm –3 dBm
15454_MRC_12
ONS-SI-155-I1-MM=
–9 dBm –14 dBm –14 dBm –5 dBm
