134
CH2: ART, PA, CVP, RAP, LAP ,LAP ,ICP ,P1,P2 limit Lo setup:
SYS: Lower SYS alarm limit: used for setting the lower alarm limit
MEA: Lower MEA alarm limit:used for setting the lower alarm limit
DIA: Lower DIA alarm limit: used for setting the lower alarm limit
Caution
Users should guarantee that zero calibration has been done on the sensor before the
measurement; otherwise the instrument has no effective zero value, which may lead to
inaccuracy of measured data.
Once the measured data exceed the alarm limits, the alarm will be triggered.
IBP alarm limits:
Pressure Scale Name
Max Upper Limit
(mmHg)
Min Lower Limit
(mmHg)
Adjustable
Single-Step Length
（mmHg）
ART 300 0 1
PA 120 -6 1
CVP 40 -10 1
RAP 40 -10 1
LAP 40 -10 1
ICP 40 -10 1
z SCALE AGJUST : The IBP waveform area provides scales for waveforms. Two
dash line of each IBP waveform, from the upper to the lower, respectively
represents the upper-limit scale and the lower-limit scale of the waveform. Values
of the two scales may be set. The detailed setting method is introduced in the
current menu.
CH1:ATR ,PA ,CVP ,RAP ,LAP ,ICP ,P1 ,P2 Setup:
• Upper scale: The pressure value represented by the upper scale limit. The
choice range is the measurement range of the current pressure.
• Lower scale: The pressure value represented by the lower scale limit. The
choice range is the measurement range of the current pressure.
• Mean scale: he pressure value represented by the middle scale limit. The
choice range is the measurement range of the current pressure.
CH2:ATR ,PA ,CVP ,RAP ,LAP ,ICP ,P1 ,P2 Setup:
• Upper scale: The pressure value represented by the upper scale limit. The
choice range is the measurement range of the current pressure.
• Lower scale: The pressure value represented by the lower scale limit. The
