DMD1050TS Satellite Modem Board
Revision 1
Technical Specifications 6–27 MN-DMD1050TS
Table 6-11. B/O/QPSK BER Performance (LDPC)
BER
Specification (dB)
Typical (dB)
1/2 Rate
2/3 Rate
3/4 Rate
1/2 Rate
2/3 Rate
3/4 Rate
1E-5
2.0
2.3
3.0
1.7
2.0
2.6
1E-6
2.1
2.4
3.1
1.8
2.1
2.7
1E-7
2.2
2.6
3.2
1.9
2.2
2.8
1E-8
2.3
2.7
3.3
2.0
2.3
2.9
Table 6-12. 8PSK / 8-QAM Rate BER Performance (LDPC)
BER
8PSK
8-QAM
Specification (dB)
Typical (dB)
Specification (dB)
Typical (dB)
2/3 Rate
3/4 Rate
2/3 Rate
3/4 Rate
2/3 Rate
3/4 Rate
2/3 Rate
3/4 Rate
1E-5
5.4
5.6
5.0
5.2
4.6
5.6
4.2
5.2
1E-6
5.5
5.7
5.1
5.3
4.7
5.7
4.3
5.3
1E-7
5.6
5.8
5.2
5.4
4.8
5.8
4.4
5.4
1E-8
5.7
5.9
5.3
5.5
4.9
5.9
4.5
5.5
Table 6-13. 16QAM BER Performance (LDPC)
BER
Specification (dB)
Typical (dB)
3/4 Rate
3/4 Rate
1E-5
6.8
6.4
1E-6
6.9
6.5
1E-7
7.0
6.6
1E-8
7.1
6.7
Table 6-14. IBS/IDR Compliant Framing Modes
BER
Specification (dB)
Typical (dB)
IBS
IDR
IBS
IDR
1/2 Rate
3/4 Rate
1/2 Rate
3/4 Rate
1E-5
5.3
6.7
5.6
5.9
1E-6
6.0
7.5
6.3
6.6
1E-7
6.6
8.2
6.9
7.3
1E-8
7.1
8.7
7.5
7.8
