DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–15 MN-DMD1050TS
7.7 Monitor and Control Menu
Use this menu to access all modem functions that are monitored and/or controlled.
The Monitor and Control menu has the following submenus:
• Transmit
• Receive
• Interface
• Monitor
• Alarms
• System
• Test
7.7.1 Transmit Menu
The Transmit menu has the following submenus:
• General/IF
• Data
• Reed Solomon
• ODU-BUC
• AUPC
• ITA
7.7.1.1 Transmit | General / IF Page
Figure 7-12. Transmit | General | IF Page Example
