DMD1050TS Satellite Modem Board
Revision 1
Appendix E E–2 MN-DMD1050TS
E.2.3 J3 & J16 Information on Supplied Interface Connectors for DC & BUC
Power
J16
DC input Power
4 Pin Crimp Terminal Hsg
Mfg (Molex) P/N: 09-50-3041
J3
BUC/LNB input
4 Pin Crimp Terminal Hsg
Mfg (Molex) P/N: 09-50-3041
E.3 Part Number Active08-56-0106
3.96 mm (.156") Pitch KK® Crimp Terminal 2478, 18-24 AWG, Bag, Brass, 0.51µm (20µ")
Selective Gold (Au)
E.3.1 Part Details
General
Status
Active
Product Name
KK®
Molex Series
2478
Gender
Female
Wire Size [AWG]
18, 20, 22, 24
Wire Insulation Diameter
2.79mm (.110") max.
Packaging
Bag
Physical
Contact
Brass (CuZn)
Contact Material Thickness
0.27mm (.011")
Plating Contact
0.5µm (20µ") Gold (Au) Selective
Plating in Crimp Area
Gold (Au) Flash Overall
Reference
Mating Pins
1.14mm (.045") Round Pin, 1.14mm (.045") Square Pin
Termination
Good Crimps
990 Catalog Page
J-62
MX01 Catalog Page
D-3, L-52
Old Part Number
2478-1-(550)L
Maximum Current 5.0 A using 18 AWG wire.
Application Tooling for 2139
Region
Description
Product Number
Americas
Extraction Tool
11-03-0016
Americas
Mini-Mac Applicator
11-18-2236
