Comtech EF Data DMD1050TS - Figure 4-1. DMD1050 TS Front View; Figure 4-2. DMD1050 TS Rear View

DMD1050TS Satellite Modem Board
Revision 1
Rear Panel Interface 4–2 MN-DMD1050TS
Figure 4-1. DMD1050TS Front View
Figure 4-2. DMD1050TS Rear View
J3
Pin 1
J3
BUC & LNB
INPUT POWER
J2
SMA
OPT (F)
RX L-BAND
J6
COMPACT
FLASH CARD
J1
SMA
OPT (F)
TX L-BAND
