DMD1050TS Satellite Modem Board
Revision 1
Appendix D D–1 MN-DMD1050TS
Appendix D. Web Browser
Setup Guide
D.1 Introduction
This section gives setup instructions to access the Web Browser through the RJ45 Ethernet
interface. The Web user interface allows for complete monitoring and control of all modem
parameters and functions, via a 10BaseT Ethernet connection.
D.2 Required Items
• Modem
• RJ45 to RJ45 CAT5 Ethernet cable
• Computer
• Default Plug/Jumper if necessary for JP1 and JP2
D.3 Web Interface Setup Guidelines
D.3.1 Prepare the DMD1050TS for Web Setup
The unit leaves the factory with the IP addresses pre-configured to an accessible IP address,
known as IP TEST MODE.
If you have difficulty getting access to the Web Browser interface, install the Default Jumper/Plug
that will change the IP addresses to an accessible address.
To reset IP addresses, install the Default Plug between pins 1 and 2 on JP1 and JP2. Jumpers
are supplied in the connector kit. This changes the IP network setting so you can get access to it.
1. Turn power off to the DMD1050TS.
2. Install the Reset jumper between pins 1 and 2 of JP1 and JP2 connector. See Figure 4-5
for the jumper location.
3. Turn power on for the DMD1050TS.
4. Let it run for two minutes.
5. Turn power off for the DMD1050TS.
6. Remove the Reset jumper from JP1 and JP2.
The IP addresses are configured as listed here:
