Comtech EF Data DMD1050TS - Table 6-17. 16 APSK BER Performance (MIL STD 188-165 B or STANAG) Turbo

DMD1050TS Satellite Modem Board
Revision 1
Technical Specifications 6–29 MN-DMD1050TS
Table 6-17. 16APSK BER Performance (MIL STD 188-165B or STANAG) Turbo
BER
16 K Block
Specification (dB)
Typical (dB)
1/2
Rate
2/3
Rate
3/4
Rate
7/8
Rate
19/20
Rate
1/2
Rate
2/3
Rate
3/4
Rate
7/8
Rate
19/20
Rate
1E-5
4.7
6.5
7.4
8.5
10.5
4.3
6.1
7.0
8.2
10.2
1E-6
4.8
6.6
7.5
8.7
10.7
4.4
6.2
7.1
8.4
10.4
1E-7
4.9
6.7
7.6
8.8
10.8
4.5
6.3
7.2
8.5
10.5
1E-8
5.0
6.8
7.7
8.9
10.9
4.6
6.4
7.3
8.6
10.6
4 K Block
1E-5
5.0
6.8
7.7
8.9
10.8
4.6
6.4
7.3
8.5
10.5
1E-6
5.1
6.9
7.8
8.9
11.0
4.7
6.5
7.4
8.7
10.7
1E-7
5.2
7.0
7.9
9.1
11.1
4.8
6.6
7.5
8.8
10.8
1E-8
5.3
7.1
8.0
9.2
11.2
4.9
6.7
7.6
8.9
10.9
1 K Block
1E-5
6.0
7.8
8.7
9.8
11.8
5.6
7.4
8.3
9.5
11.5
1E-6
6.1
7.9
8.8
9.9
12.0
5.7
7.5
8.4
9.7
11.7
1E-7
6.2
8.0
8.9
10.1
12.1
5.8
7.6
8.5
9.8
11.8
1E-8
6.3
8.1
9.0
10.2
12.2
5.9
7.7
8.6
9.8
11.9
