Comtech EF Data DMD1050TS - Table I-2. Initial Modem Setup

DMD1050TS Satellite Modem Board
Revision 1
Appendix I I–3 MN-DMD1050TS
I.1.2.1 Initial DMD1050TS Modem Setup
Table I-2. Initial Modem Setup
FW: F05280-AH28 REV 4.4.28 (7/06 9:47)
MAIN MENU MENU OPTION PARAMENTER
VALUE
PARAMENTER VALUE
INTERFACE
TX SETUP TERR INTERFACE MIL-188-114A
TERR INTERFACE
MIL-188-114A
INTERFACE RX SETUP
TERR INTERFACE MIL-188-114A
TERR INTERFACE MIL-188-114A
MODULATOR
NETWORK-SPEC NETWORK SPEC EBEM
NETWORK SPEC EBEM
MODULATOR IF FREQUENCY (MHz)
137.5 MHz
FREQUENCY (MHz) 142.5 MHz
MODULATOR
IF
POWER (dBm) -25 POWER (dBm)
-25
MODULATOR
IF
CARRIER ON CARRIER
ON
MODULATOR IF
SPECTRUM NORMAL SPECTRUM
NORMAL
MODULATOR IF
MODULATION
BPSK MODULATION
BPSK
MODULATOR IF SPECTRAL MASK
MIL188 165A SPECTRAL MASK MIL188 165A
MODULATOR DATA
DATA RATE (bps) 2048000
DATA RATE (bps)
2048000
MODULATOR DATA
INNER FEC
TURBO 2/3 INNER FEC TURBO 2/3
MODULATOR DATA
IFEC INTERLEAVE DISABLED IFEC INTERLEAVE
DISABLED
MODULATOR
DATA
DIFF CODING DISABLED DIFF CODING
DISABLED
MODULATOR DATA SCRAMBLER SEL
EBEM
SCRAMBLER SEL EBEM
MODULATOR DATA SCRAMBLER CTRL
ENABLED
SCRAMBLER CTRL ENABLED
MODULATOR
DATA SAT FRAMING EBEM
SAT FRAMING EBEM
MODULATOR DATA
OVERHEAD CHAN OFF
OVERHEAD CHAN OFF
MODULATOR
DATA EMBEDDED CHAN
ENABLED EMBEDDED CHAN ENABLED
MODULATOR DATA
ENCRYPTION DISABLED ENCRYPTION
DISABLED
MODULATOR DATA
ETH RATE (bps) 640000
ETH RATE (bps) 640000
N/A
N/A
N/A
N/A N/A
N/A
N/A N/A N/A N/A N/A
N/A
N/A N/A
N/A N/A N/A
N/A
MODULATOR
ITA ITA OPTION DISABLED ITA OPTION DISABLED
MODULATOR ITA
(see ITA submenu Setup) N/A (see ITA submenu Setup)
N/A
MODULATOR REED-SOLOMON ENABLE/DISABLE
DISABLE ENABLE/DISABLE
DISABLE
DEMODULATOR NETWORK-SPEC NETWORK SPEC
EBEM NETWORK SPEC EBEM
DEMODULATOR IF FREQUENCY (MHz)
142.5 MHz FREQUENCY (MHz)
137.5 MHz
DEMODULATOR IF
SPECTRUM NORMAL SPECTRUM
NORMAL
DEMODULATOR IF
MODULATION BPSK MODULATION
BPSK
DEMODULATOR IF
SPECTRAL MASK MIL188 165A SPECTRAL MASK
MIL188 165A
DEMODULATOR
DATA DATA RATE (bps) 2048000
DATA RATE (bps) 2048000
DEMODULATOR
DATA INNER FEC TURBO 2/3
INNER FEC TURBO 2/3
DEMODULATOR
DATA IFEC INTERLEAVE DISABLED
IFEC INTERLEAVE DISABLED
DEMODULATOR
DATA DIFF CODING DISABLED
DIFF CODING DISABLED
DEMODULATOR
DATA SCRAMBLER SEL EBEM
SCRAMBLER SEL EBEM
DEMODULATOR
DATA SCRAMBLER CTRL ENABLED SCRAMBLER CTRL
ENABLED
DEMODULATOR DATA SAT FRAMING EBEM
SAT FRAMING EBEM
DEMODULATOR DATA OVERHEAD CHAN OFF
OVERHEAD CHAN OFF
DEMODULATOR DATA EMBEDDED CHAN ENABLED
EMBEDDED CHAN ENABLED
DEMODULATOR DATA ENCRYPTION DISABLED
ENCRYPTION DISABLED
DEMODULATOR DATA ETH RATE (bps) 640000
ETH RATE (bps) 640000
N/A N/A N/A N/A N/A
N/A
N/A N/A N/A N/A
N/A N/A
DEMODULATOR
ITA ITA OPTION DISABLED
ITA OPTION DISABLED
DEMODULATOR
ITA (see ITA submenu Setup) N/A (see ITA submenu Setup) N/A
N/A N/A N/A N/A
N/A N/A
N/A N/A
N/A N/A N/A N/A
DEMODULATOR REED-SOLOMON
ENABLE/DISABLE DISABLE ENABLE/DISABLE DISABLE
INTERFACE RX SETUP BUFF SIZE (msec)
0 BUFF SIZE (msec) 0
INTERFACE
RX SETUP BUFFER CLK SRC, PRIORITY, SRC DEPTH
RX SAT, 1, 1 BUFFER CLK SRC, PRIORITY, SRC DEPTH
RX SAT, 1, 1
INTERFACE RX SETUP BUFFER CLOCK POL
NORMAL BUFFER CLOCK POL NORMAL
MONITOR RX BUFFER RESET PRESS ENTER TO RECENTER
ENTER PRESS ENTER TO RECENTER ENTER
DMD2050E MENU SETTINGS (UUT)
DMD2050E MENU SETTINGS (Reference)
