DMD1050TS Satellite Modem Board
Revision 1
Appendix E E–1 MN-DMD1050TS
Appendix E. User Interface
Connections
E.1 User Interface Connections
Supplied mating connectors can be used, but are not required.
E.2 Connector Kit part numbers
CEFD P/N
Description
Connector Location
1. CA/3446-9
MIL-STD-188-114A
J4
2. CONN0003-040
Shorting/default plug
JP1 & JP2
3. CNR102387-1
Dual Row header 10 Pin
J3
4. CNR102387-6
Dual Row Header 26 Pin
J4
5. TMR102548-6
Receptacle Contacts
J3 & J4
6. CN/MOL04F12
Conn Crimp 4 Terminal Housing
J3 & J16
7. TM/CPF08
Terminal crimp 18-24AWG for 2139
J3 & J16
E.2.1 J3 & J4 Interface Connectors located on PCB
• J3: Async Interface Connector - 10Pin Dual Row: Mfg (Samtec) P/N: TSW-1-05-7-G-D
• J4: Mil 188-114A Connector - 26Pin Dual Row: Mfg (Samtec) P/N: TSW-1-13-7-G-D
• MFG: Samtec connector information
o TSW = Terminal strip series
o -1 = .100” Centers
o 05 or 13 = Number of pins per row
o 7 = Straight pin version dimensions
Dimensions (inches)
Style
A
B
C
-07
.100
0.430
0.430
o G =
Gold plating
o D = Dual Row.
E.2.2 J3 & J4 Information on Supplied Interface Connectors
J3
Async Interface
10Pin Dual Row:
Mfg (Tyco) P/N: 102387-1
J4
Mil 188-114A
26Pin Dual Row:
Mfg (Tyco) P/N: 102548-6
J16
Receptacle Contacts
Mfg (Tyco) P/N: 1-87309-4
