Comtech EF Data DMD1050TS - EBEM Modes; Non-DVB Modes

DMD1050TS Satellite Modem Board
Revision 1
Technical Specifications 6–2 MN-DMD1050TS
6.1.2 EBEM Modes
EBEM Modes
Modulation
Code Rate
Min Data Rate (Kbps)
Max Data Rate (Mbps)
BPSK
1/2
64
4.965
1
BPSK
2/3
64
6.614
1
BPSK
3/4
64
7.436
1
BPSK
7/8
64
8.673
1
BPSK
19/20
64
9.412
1
QPSK
1/2
64
9.905
1
QPSK
2/3
64
13.180
1
QPSK
3/4
64
14.811
1
QPSK
7/8
64
17.253
1
QPSK
19/20
64
18.716
1
8PSK
1/2
256
14.811
1
8PSK
2/3
256
19.691
1
8PSK
3/4
256
22.119
1
8PSK
7/8
256
25.746
1
8PSK
19/20
256
27.911
1
16APSK
1/2
256
19.691
1
16APSK
2/3
256
26.150
1
16APSK
3/4
256
29.356
1
16APSK
7/8
256
34.145
1
16APSK
19/20
256
37.008
1
6.1.3 Non-DVB Modes
Non-DVB Modes
Modulation
Code Rate
Min Data Rate
Max Data Rate
BPSK
NONE
4800
10000000
BPSK
VIT 1/2
2400
5000000
BPSK
VIT 3/4
3600
7500000
BPSK
VIT 7/8
4200
8750000
BPSK
SEQ 1/2
2400
2048000
BPSK
SEQ 3/4
3600
2048000
BPSK
SEQ 7/8
4200
2048000
BPSK
TPC 5/16
2400
3125000
BPSK
TPC 21/44
2400
4772727
BPSK
TPC 3/4
3600
7500000
BPSK
TPC 7/8
4200
8750000
BPSK
LDPC 1/2
2400
5000000
BPSK
EBEM TURBO 1/2
64000
4965315
BPSK
EBEM TURBO 2/3
64000
6613713
1
Max STAMAG rates reflect the maximum user payload with th embedded channel ENABLED.
This is either Ethernet or Mixed Mode with the serial MIL-STD-188-114A and is limited to 20 Mbps.
