DMD1050TS Satellite Modem Board
Revision 1
Technical Specifications 6–4 MN-DMD1050TS
Non-DVB Modes
Modulation
Code Rate
Min Data Rate
Max Data Rate
8QAM
TPC 3/4
10800
20000000
8QAM
TPC 7/8
12600
20000000
8QAM
LDPC 2/3
9600
20000000
8QAM
LDPC 3/4
10800
20000000
16QAM
VIT 3/4
14400
20000000
16QAM
VIT 7/8
16800
20000000
16QAM
TPC 3/4
14400
20000000
16QAM
TPC 7/8
16840
20000000
16QAM
LDPC 3/4
14400
20000000
16APSK
EBEM TURBO 1/2
256000
19691268
16APSK
EBEM TURBO 2/3
256000
26149903
16APSK
EBEM TURBO 3/4
256000
29356346
16APSK
EBEM TURBO 7/8
256000
34144709
16APSK
EBEM TURBO 19/20
256000
37008159
6.1.4 DVB Modes
187 Mode
Modulation
Code Rate
Min Data Rate
Max Data Rate
BPSK
VIT 1/2
2400
4583333
BPSK
VIT 2/3
2934
6111111
BPSK
VIT 3/4
3300
6875000
BPSK
VIT 5/6
3667
7638888
BPSK
VIT 7/8
3850
8020833
QPSK
VIT 1/2
4400
9166666
QPSK
VIT 2/3
5867
12222222
QPSK
VIT 3/4
6600
13750000
QPSK
VIT 5/6
7334
15277777
QPSK
VIT 7/8
7700
16041666
8PSK
TRE 2/3
8800
18333333
8PSK
TRE 5/6
11000
20000000
8PSK
TRE 8/9
11550
20000000
16QAM
TRE 3/4
13200
20000000
16QAM
TRE 7/8
15400
20000000
