Comtech EF Data DMD1050TS - Page 95

DMD1050TS Satellite Modem Board
Revision 1
Technical Specifications 6–5 MN-DMD1050TS
188 Mode
Modulation
Code Rate
Min Data Rate
Max Data Rate
BPSK
VIT 1/2
2400
4607843
BPSK
VIT 2/3
2950
6143790
BPSK
VIT 3/4
3318
6911764
BPSK
VIT 5/6
3687
7679738
BPSK
VIT 7/8
3871
8063725
QPSK
VIT 1/2
4424
9215686
QPSK
VIT 2/3
5899
12287581
QPSK
VIT 3/4
6636
13823529
QPSK
VIT 5/6
7373
15359476
QPSK
VIT 7/8
7742
16127450
8PSK
TRE 2/3
8848
18431372
8PSK
TRE 5/6
11059
20000000
8PSK
TRE 8/9
11797
20000000
16QAM
TRE 3/4
13271
20000000
16QAM
TRE 7/8
15483
20000000
204 Mode
Modulation
Code Rate
Min Data Rate
Max Data Rate
BPSK
VIT 1/2
2400
5000000
BPSK
VIT 2/3
3200
6666666
BPSK
VIT 3/4
3600
7500000
BPSK
VIT 5/6
4000
8333333
BPSK
VIT 7/8
4200
8750000
QPSK
VIT 1/2
4800
10000000
QPSK
VIT 2/3
6400
13333333
QPSK
VIT 3/4
7200
15000000
QPSK
VIT 5/6
8000
16666666
QPSK
VIT 7/8
8400
17500000
8PSK
TRE 2/3
9600
20000000
8PSK
TRE 5/6
12000
20000000
8PSK
TRE 8/9
12800
20000000
16QAM
TRE 3/4
14400
20000000
16QAM
TRE 7/8
16800
20000000
