DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–12 MN-DMD1050TS
Table 7-2. SNMP Parameters
SNMP VERSION: V1 & V2
TRAP VERSION: V1
AUTHORIZATION: TRAPS OFF
RD COMMUNITY: PUBLIC
RDWR COMMUNITY: PUBLIC
USER 1
Viewer-md5
USER 2
Viewer-sha
USER 3
Oper-md5
USER 4
Oper-sha
ACCESS GROUP
VIEWER
ACCESS GROUP
VIEWER
ACCESS GROUP
OPER
ACCESS GROUP
OPER
AUTH PASSWORD
Viewer
AUTH PASSWORD
Viewer
AUTH PASSWORD
Oper
AUTH PASSWORD
Oper
PRIV PASSWORD
Viewer
PRIV PASSWORD
Viewer
PRIV PASSWORD
Oper
PRIV PASSWORD
Oper
AUTHENTICATION
MD5
AUTHENTICATION
SHA
AUTHENTICATION
MD5
AUTHENTICATION SHA
PRIVACY
DES
PRIVACY
DES
PRIVACY
DES
PRIVACY
DES
Table 7-3. Web Parameters
WEB MENU
Confirmation
•
ENABLED
• DISABLED
Enable or disable a confirmation response if a
change is made to the modem output.
User 1
User 2
User 3
Access Group
• NO GROUP
• GUEST
• OPER
• ADMIN
NO GROUP: Denies all access.
GUEST: Guests can access most of the site to
see modem parameters.
OPER: Operators can monitor and control
parameter settings, and change their own
authentication passwords.
ADMIN: Administrators can monitor and control
the parameters, change any user’s name and
authentication password, and modify IP network
settings. ADMIN setting gives access to the entire
site.
Authorization
Password
xxxxxxxx
User to select password. The user can modify the
Authorization Passwords. The user name can have
up to 14 characters supporting alpha and numeric
characters. Alpha characters can be entered using
the up and down arrow keys. Numeric characters
can be selected by using the number keys on the
front panel. The user can clear all characters from
the front panel screen.
User Reset Resets group and password.
