DMD1050TS Satellite Modem Board
Revision 1
TRANSEC Module SSH CLI Operation 9–3 MN-DMD1050TS
9.2 Command Line Interface (CLI)
9.2.1 CLI Menu System – Parallel Functionality
The CLI allows you to change operating parameters in a manner similar to that of monitor,
configure and control functions using the Web browser menus. See Chapter 8.
9.2.2 CLI Menu – Common Information, Navigation, Operation Features
With some exceptions, the screen examples in this chapter use these standards:
[Text field example] [RO]
Typically found in the body of the screen.
This means the field is a read-only status/informational message. No
user action is required for this item.
Logout of Administration
Session
L
Found at the bottom of the screen.
Allows you to log out of the SSH session.
Exit Menu X
Found at the bottom of the screen.
Allows you to exit the current menu and return to the parent menu.
Alternately, press the Esc key to do the same action.
Typically, once any mnemonic is entered, you are prompted to type in a functional selection, an
alphanumeric configuration string, or an operational value. This prompt shows at the bottom of
the active screen. It is a selection choice and/or a blank prompt (a solid bar), as shown in this
example:
If a parameter is rejected for any reason, an error shows at the top of the screen, along with an
explanation:
