DMD1050TS Satellite Modem Board
Revision 1
Installation 2–1 MN-DMD1050TS
Chapter 2. Installation
2.1 Unpacking and Inspection
Do not use any cutting tool that will extend more than 1/2 inch into the
container. This can cause damage to the modem.
Inspect shipping containers for damage. If shipping containers are damaged, keep them until the
contents of the shipment have been carefully inspected and checked for normal operation.
The Satellite Modem Board and its Installation and Operation Manual are packaged and shipped in
a pre-formed, reusable cardboard carton containing foam spacing for maximum shipping protection.
Unpack and inspect the modem as follows:
1
Cut the tape at the top of the carton indicated by OPEN THIS END.
Remove the cardboard/foam space covering the modem.
Remove the modem and user’s manual from the carton.
4 Save the packing material for storage or reshipment purposes.
Inspect the equipment for any possible damage incurred during shipment.
Note: If damage is evident, contact the carrier and Comtech EF Data immediately
and submit a damage report.
Check the contents against the packing list to verify completeness of the
shipment.
Refer to the sections that follow for further installation instructions.
The Universal Satellite Modem was carefully packaged to avoid damage and should arrive
complete with the following items for proper installation:
1. DMD1050TS Satellite Modem Board
2. Installation and Operation Manual
