DMD1050TS Satellite Modem Board
Revision 1
Rear Panel Interface 4–3 MN-DMD1050TS
Figure 4-3. RF Board (PL-0021834)
J10
TWIN RJ45
ETHERNET
DATA
J11
RJ45
M&C
HIGH
STABILITY
OSCILLATOR
J9
SMA
FEMALE
J16
INPUT POWER
24V
J2 SMA
OPT (F)
RX L-BAND
J6
COMPACT
FLASH CARD
J1 SMA
OPT (F)
TX L-BAND
