Comtech EF Data DMD1050TS - Low Speed Mesh Applications

DMD1050TS Satellite Modem Board
Revision 1
Appendix F F–5 MN-DMD1050TS
F.6 Low Speed Mesh Applications
For mesh applications with data rates lower than 5 Mbps, the combination of a DMD20 and an
MD2401 Multi-Demodulator can provide a simple 8PSK with Turbo solution that requires no IP
configuration or network setup. See Figure F-5.
When configured with the Ethernet option, the MD2401 automatically multiplexes the packets
received from the multiple data streams onto a single 10/100 Ethernet port.
Figure F-5. Low Speed Mesh
DMD20
MD2401
Router
Daisy Chain
LAN 1
DMD20
MD2401
Router
Daisy Chain
LAN 2
DMD20
MD2401
Router
Daisy Chain
LAN 3
DMD20
MD2401
Router
Daisy Chain
LAN 4
DMD20
MD2401
Router
Daisy Chain
LAN 5
DMD20
MD2401
Router
Daisy Chain
LAN 6
