Technical Specifications 6–3 MN-DMD1050TS
Non-DVB Modes
Modulation
Code Rate
Min Data Rate
Max Data Rate
BPSK
EBEM TURBO 3/4
64000
7436434
BPSK
EBEM TURBO 7/8
64000
8673111
BPSK
EBEM TURBO 19/20
64000
9412035
QPSK
NONE
9600
20000000
QPSK
VIT 1/2
4800
10000000
QPSK
VIT 3/4
7200
15000000
QPSK
VIT 7/8
8400
17500000
QPSK
SEQ 1/2
4800
2048000
QPSK
SEQ 3/4
7200
2048000
QPSK
SEQ 7/8
8400
2048000
QPSK
TPC 21/44
4582
9545454
QPSK
TPC 3/4
7200
15000000
QPSK
TPC 7/8
8400
17500000
QPSK
LDPC 1/2
4800
10000000
QPSK
LDPC 2/3
6400
13333333
QPSK
LDPC 3/4
7200
15000000
QPSK
EBEM TURBO 1/2
64000
9905362
QPSK
EBEM TURBO 2/3
64000
13180497
QPSK
EBEM TURBO 3/4
64000
14811320
QPSK
EBEM TURBO 7/8
64000
17252747
QPSK
EBEM TURBO 19/20
64000
18716185
OQPSK
NONE
9600
20000000
OQPSK
VIT 1/2
4800
10000000
OQPSK
VIT 3/4
7200
15000000
OQPSK
VIT 7/8
8400
17500000
OQPSK
SEQ 1/2
4800
2048000
OQPSK
SEQ 3/4
7200
2048000
OQPSK
SEQ 7/8
8400
2048000
OQPSK
TPC 21/44
4582
9545454
OQPSK
TPC 3/4
7200
15000000
OQPSK
TPC 7/8
8400
17500000
OQPSK
LDPC 1/2
4800
10000000
OQPSK
LDPC 2/3
6400
13333333
OQPSK
LDPC 3/4
7200
15000000
8PSK
TRE 2/3
9600
20000000
8PSK
TPC 3/4
10800
20000000
8PSK
TPC 7/8
12600
20000000
8PSK
LDPC 2/3
9600
20000000
8PSK
LDPC 3/4
10800
20000000
8PSK
EBEM TURBO 1/2
256000
14811320
8PSK
EBEM TURBO 2/3
256000
19691268
8PSK
EBEM TURBO 3/4
256000
22118667
8PSK
EBEM TURBO 7/8
256000
25745821
8PSK
EBEM TURBO 19/20
256000
27911111
