DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–70 MN-DMD1050TS
Test | Pattern / Carrier Page
Loopback Type • NONE
• TERR RX
• BASEBAND RX
• TERR TX
• BASEBAND TX
• IFEC TX
• IF
• TERR TX/RX
• BASEBAND TX/RX
Pattern Ber
• NO SYNC
• nnnn x 10
-n
This shows the measured Bit Error Rate for the received
test pattern.
Pattern Error Count
•
NO SYNC
• nnnn x 10
n
This shows the number of errors detected by the test
pattern checker.
Carrier Type
• NORMAL
• CW
• DUAL
• OFFSET
• POS FIR
• NEG FIR
RESTART TEST
PATTERN
Use to reset the test pattern counter and generator.
