DMD1050TS Satellite Modem Board
Revision 1
TRANSEC Module HTTPS Interface 8–11 MN-DMD1050TS
8.4.2.2 Transmit Status
Displays the number of transmitted AES 256 frames.
Describes the value of the Tx Status register.
Displays the state of the Tx DCM lock.
Displays the encryption status (Bypass on means Encryption off).
Crypto Traffic
When Detected, the module has sampled outgoing traffic and verifies it has been
encrypted. When Not Detected, encryption is off, or the module cannot verify
8.4.2.3 Receive Status
Displays the count of received CRC errors.
Displays the number of received AES 256 frames.
Displays the value of the Rx Status register.
Displays the state of the Rx DCM lock.
Unique Word Lock
Indicates that the decryption engine has successfully found the unique word and has
been able to lock to it.
Indicates that an out-of-sync condition has been detected by the encryption engine.
8.4.2.4 Automatic Refresh Status Timer
The page updates itself automatically for the duration of the countdown timer. When the timer
reaches 0:00, the page will stop updating to help conserve system resources.
To manually override the timer, click Stop to interrupt or Reset to restart the timer.
