Appendix G G–3 MN-DMD1050TS
Strap Code (Decimal)
Data Rate (Kbps)
Overhead
Code Rate
Type
Framing Type
Scrambler Type
Reed-Solomon
Modulation
Mode
30
1088
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
39
1088
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
43
1152
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
46
1152
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
51
1216
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
53
1216
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
54
1280
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
57
1280
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
58
1344
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
67
1408
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
71
1408
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
75
1472
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
77
1472
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
78
1600
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
83
1600
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
85
1664
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
86
1664
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
89
1728
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
90
1728
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
92
1792
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
99
1792
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
102
1856
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
105
1856
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
106
2048
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
135
1984
16/15
1/2
VIT
IBS
IBS
Dis
QPSK
CNT
139
1984
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
45
3088
1
1/2
VIT
NONE
V.35 (IESS)
Dis
QPSK
CNT
141
3088
1
3/4
VIT
NONE
V.35 (IESS)
Dis
QPSK
CNT
176
4000
1
1/2
VIT
NONE
V.35 (IESS)
Dis
QPSK
CNT
116
4000
1
3/4
VIT
NONE
V.35 (IESS)
Dis
QPSK
CNT
60
1344
16/15
3/4
VIT
IBS
IBS
Dis
QPSK
CNT
