DMD1050TS Satellite Modem Board
Revision 1
Appendix I I–10 MN-DMD1050TS
Table I-7. ITA Waveform Masks (Demodulator UUT)
DMD1050TS Menu Settings (UUT)
Main Menu
Menu Option
Parameter
Value
DEMODULATOR
ITA
BPSK 1/2
NOT SELECTSED
DEMODULATOR
ITA
BPSK 2/3
SELECTED
DEMODULATOR
ITA
BPSK 3/4
NOT SELECTSED
DEMODULATOR
ITA
BPSK 7/8
NOT SELECTSED
DEMODULATOR
ITA
BPSK 19/20
NOT SELECTSED
DEMODULATOR
ITA
QPSK 1/2
NOT SELECTSED
DEMODULATOR
ITA
QPSK 2/3
SELECTED
DEMODULATOR
ITA
QPSK 3/4
NOT SELECTSED
DEMODULATOR
ITA
QPSK 7/8
NOT SELECTSED
DEMODULATOR
ITA
QPSK 19/20
NOT SELECTSED
DEMODULATOR
ITA
8PSK 1/2
NOT SELECTSED
DEMODULATOR
ITA
8PSK 2/3
NOT SELECTSED
DEMODULATOR
ITA
8PSK 3/4
SELECTED
DEMODULATOR
ITA
8PSK 7/8
NOT SELECTSED
DEMODULATOR
ITA
8PSK 19/20
NOT SELECTSED
DEMODULATOR
ITA
16APSK 1/2
SELECTED
DEMODULATOR
ITA
16APSK 2/3
NOT SELECTSED
DEMODULATOR
ITA
16APSK 3/4
NOT SELECTSED
DEMODULATOR
ITA
16APSK 7/8
SELECTED
DEMODULATOR
ITA
16APSK 19/20
SELECTED
