Instruction Manuals: Installation, Operators Maintenance Standard 360a Model Y (360y) Label Applicator
x
SYSTEM REQUIREMENTS
Electrical Requirements
• 108 – 132 VAC, 1 Ø
• 10 AMPS, 10K SCCR
• 50/60 Hertz, Single-Phase
• Power cable:
o 3m long.
o 3-wire cable.
o 16 AWG (1.00mm
2
) conductors rated at 10 amperes (in accordance with CENELEC HD-21) provided for the
electrical connection to the IEC 320 receptacle of the applicator.
o End of the power cord is terminated with a NEMA5-15 plug.
NOTE: The applicator should not be plugged into GFCI outlets.
Air Requirements
• 80 PSI clean dry air (for non-merge applicators)
• 4 SCFM
NOTE: In tamp applications an increase in venturi vacuum pressure may lead to higher SCFM usage
Operating Environment
• Ambient Operating Temperature: 40° F – 104° F
• Ambient Operating Humidity: 20% – 90% RH, non-condensing
• Ambient Storage Temperature: -4° F – 140° F
• Ambient Storage Humidity: 0% – 90% RH, non-condensing
• Operating Altitude 3280ft above sea level or lower
• The 360a Model Y Label Applicator is not intended to be operated in a hazardous location—an
environment where flammable or explosive gasses or materials are present. Installation in a hazardous
location might lead to an explosion causing personal injury or equipment damage.
• The 360a Model Y Label Applicator is not to be used in direct contact with food products.
