CTM 360y - Merge Spare Parts; Air Blow Spare Parts; RVB Spare Parts

Maintenance Manual: Standard 360a Model Y (360y) Label Applicator
22
Spare Parts
03/2023
Merge Spare Parts
MERGE SPARE PARTS LIST
WEAR ITEM
Part Number
Recommended Qty
Description
PM-T1000 or
1
UHMW TAPE FOR 5" PEEL EDGE ( 5 7/16" Wide x 7" Lg.)
PM-T1015
1
UHMW TAPE FOR 7.5" & 10" PEEL EDGE (8" Wide x 7" Lg.)
ASS-215-0110X-X or
1
5" WIPER ASSEMBLY (specify length & material)
ASS-215-2110X-X or
1
7.5" WIPER ASSEMBLY (specify length & material)
ASS-215-5110X-X
1
10" WIPER ASSEMBLY (specify length & material)
Air Blow Spare Parts
AIR BLOW SPARE PARTS LIST
WEAR ITEM
Part Number
Recommended Qty
Description
PM-T1000 or
1
UHMW TAPE FOR 5" PEEL EDGE ( 5 7/16" Wide x 7" Lg.)
PM-T1015
1
UHMW TAPE FOR 7.5" & 10" PEEL EDGE (8" Wide x 7" Lg.)
ASS-215-0110X-X or
1
5" WIPER ASSEMBLY (specify length & material)
ASS-215-2110X-X or
1
7.5" WIPER ASSEMBLY (specify length & material)
ASS-215-5110X-X
1
10" WIPER ASSEMBLY (specify length & material)
PM-T1000 or
1
UHMW TAPE FOR 5" PEEL EDGE ( 5 7/16" Wide x 7" Lg.)
PM-T1015
1
UHMW TAPE FOR 7.5" & 10" PEEL EDGE (8" Wide x 7" Lg.)
RECOMMENDED SPARE PARTS
Part Number
Recommended Qty
Description
MP-211-0217-7
1
AIR ASSIST TUBE **THIS IS JOB SPECIFIC**
ASS-211-0103 or
1
AIR TUBE MANIFOLD ASSEMBLY
ASS-211-0103E
1
AIR TUBE MANIFOLD ASSEMBLY FOR EXT. BLOW BOX
EXTENDED SPARE PARTS
Part Number
Recommended Qty
Description
PM-FIL1010
1
WATTS FILTER
PM-VA2395M
1
5.4 WATT DC SOLENOID
PM-VA2396M
1
60 PSI AIR ASSIST REGULATOR
PM-VA2397M
1
80 PSI TAMP/BLOW REGULATOR
ASS-211-0106M
1
AIR BLOW 2-STATION VALVE BANK ASSEMBLY
ASS-211-0109
1
AIR FILTER REGULATOR ASSEMBLY
RVB Spare Parts
RVB SPARE PARTS LIST
WEAR ITEM
Part Number
Recommended Qty
Description
PM-T1010 or
1
UHMW TAPE FOR 5" PEEL EDGE ( 6" Wide x 4" Lg.)
PM-T1015
1
UHMW TAPE FOR 7.5" PEEL EDGE (8" Wide x 4" Lg.)
ASS-215-0110X-X or
1
5" WIPER ASSEMBLY (specify length & material)
ASS-215-2110X-X or
1
7.5" WIPER ASSEMBLY (specify length & material)
ASS-215-5110X-X
1
10" WIPER ASSEMBLY (specify length & material)
RECOMMENDED SPARE PARTS
Part Number
Recommended Qty
Description
MP-211-0217-7
1
AIR ASSIST TUBE **THIS IS JOB SPECIFIC**
EXTENDED SPARE PARTS
Part Number
Recommended Qty
Description
PM-FIL1010
1
WATTS FILTER
PM-VA2395M
1
5.4 WATT DC SOLENOID
PM-VA2396M
1
60 PSI AIR ASSIST REGULATOR
PM-VA2397M
1
80 PSI TAMP/BLOW REGULATOR
ASS-211-0112M
1
RVB 2-STATION VALVE BANK ASSEMBLY
