CTM 360y - Non-Powered Unwind Assembly Spare Parts

Maintenance Manual: Standard 360a Model Y (360y) Label Applicator
21
Spare Parts
03/2023
Non-powered Unwind Assembly Spare Parts
NON-POWERED UNWIND ASSEMBLY SPARE PARTS LIST
WEAR ITEMS
Part Number
Recommended Qty
Description
PM-OR1007
1
O-RING
RECOMMENDED SPARE PARTS (12" NON-POWERED UNWIND)
Part Number
Recommended Qty
Description
PM-BEBF1015
1
FF-520-10 DANCER ARM BUSHING
PM-BE1266
2
DANCER ARM THRUST BEARING
PM-FASP30437
1
TENSION SPRING
ASS-200-0134
1
UNWIND BEARING BLOCK ASSEMBLY
SAS-200-0131 or
1
5" DANCER ROLLER ASSEMBLY w/o SHAFT
SAS-200-2131 or
1
7.5" DANCER ROLLER ASSEMBLY w/o SHAFT
SAS-200-5131
1
10" DANCER ROLLER ASSEMBLY w/o SHAFT
RECOMMENDED SPARE PARTS (16" & 20" NON-POWERED UNWIND)
Part Number
Recommended Qty
Description
PM-BEBF1015
1
FF-520-10 DANCER ARM BUSHING
PM-BE1266
2
DANCER ARM THRUST BEARING
PM-FASP30480
1
TENSION SPRING
ASS-200-0134
1
UNWIND BEARING BLOCK ASSEMBLY
SAS-200-0135 or
2
5" TENSION ROLLER ASSEMBLY w/o SHAFT
SAS-200-2135 or
2
7.5" TENSION ROLLER ASSEMBLY w/o SHAFT
SAS-200-5135
2
10" TENSION ROLLER ASSEMBLY w/o SHAFT
STANDARD REWIND ASSEMBLY SPARE PARTS LIST
WEAR ITEMS (STANDARD REWIND)
Part Number
Recommended Qty
Description
ASS-200-0143
1
REWIND - SLIP CLUTCH ASSEMBLY
PM-BELT1023
1
REWIND - TIMING BELT
PM-CL1010
1
REWIND - 3" LEATHER CLUTCH PAD
EXTENDED SPARE PARTS (STANDARD REWIND)
Part Number
Recommended Qty
Description
ASS-200-0128R or
1
REWIND BEARING BLOCK ASSEMBLY W/ SHAFT
ASS-200-0128L
1
REWIND BEARING BLOCK ASSEMBLY W/ SHAFT
PM-BE1232
1
REWIND - CLUTCH THRUST WASHER
NON-POWERED UNWIND with POWERED REWIND SPARE PARTS LIST
WEAR ITEMS (16" & 20" NON-POWERED with POWERED REWIND)
Part Number
Recommended Qty
Description
PM-OR1040
1
CLEAR O-RING
RECOMMENDED SPARE PARTS (16" & 20" NON-POWERED with POWERED REWIND)
Part Number
Recommended Qty
Description
ASS-200-0460
1
PROXIMITY SWITCH
PE-FU2065
1
3 AMP FUSE
PE-MC1109
1
MOTOR DRIVER CONTROLLER
PE-MO1008
1
LEESON GEAR MOTOR
PE-PO1030
1
5K SPEED POTENTIONMETER
PE-RE1063
3
RELAY
PE-RE1013
1
SOLID STATE RELAY
PE-SI1050
1
ISOLATER BOARD
PM-BEBF1015
1
FF-520-10 DANCER ARM BUSHING
PM-BE1266
2
DANCER ARM THRUST BEARING
PM-FASP30480
1
TENSION SPRING
ASS-200-0134
1
UNWIND BEARING BLOCK ASSEMBLY
