Maintenance Manual: Standard 360a Model Y (360y) Label Applicator
24
Spare Parts
03/2023
Swing Tamp
SWING TAMP SPARE PARTS LIST
WEAR ITEM
Part Number
Recommended Qty
Description
PM-T1010 or
1
UHMW TAPE FOR 5" PEEL EDGE (6" Wide x 4" Lg.)
PM-T1015 or
1
UHMW TAPE FOR 7.5" PEEL EDGE (8" Wide x 4" Lg.)
ASS-215-0110X-X or
1
5" WIPER ASSEMBLY (specify length & material)
ASS-215-2110X-X or
1
7.5" WIPER ASSEMBLY (specify length & material)
ASS-215-5110X-X
1
10" WIPER ASSEMBLY (specify length & material)
RECOMMENDED SPARE PARTS
Part Number
Recommended Qty
Description
MP-211-0217-7
1
AIR ASSIST TUBE **JOB SPECIFIC**
EXTENDED SPARE PARTS
Part Number
Recommended Qty
Description
PM-FIL1010
1
WATTS FILTER
PM-VA2395M
1
5.4 WATT DC SOLENOID
PM-VA2396M
1
60 PSI AIR ASSIST REGULATOR
PM-VA2397M
1
800 PSI TAMP/BLOW REGULATOR
ASS-214-0105M
1
TAMP 3-STATION VALVE BANK ASSEMBLY
PM-SA0990
1
SHOCK ABSORBER (HOME)
PM-SA1000
1
SHOCK ABSORBER (EXTEND)
ROTARY ACTUATOR
Part Number
Recommended Qty
Description
PM-AC1250 1
STANDARD DUTY ROTARY ACTUATOR
NOTE: Contact Sales Department for heavy duty rotary actuator.
DAT
DUAL ACTION TAMP SPARE PARTS LIST
WEAR ITEM
Part Number
Recommended Qty
Description
PM-T1010 or
1
UHMW TAPE FOR 5" PEEL EDGE (6" Wide x 4" Lg.)
PM-T1015 or
1
UHMW TAPE FOR 7.5" PEEL EDGE (8" Wide x 4" Lg.)
PM-T1010
1
UHMW TAPE FOR 10" PEEL EDGE (6" Wide x 11" Lg.)
ASS-215-0110X-X or
1
5" WIPER ASSEMBLY (specify length & material)
ASS-215-2110X-X or
1
7.5" WIPER ASSEMBLY (specify length & material)
ASS-215-5110X-X
1
10" WIPER ASSEMBLY (specify length & material)
RECOMMENDED SPARE PARTS
Part Number
Recommended Qty
Description
PM-SA0950
2
SHOCK ABSORBER
PM-SA0990
1
SHOCK ABSORBER (HOME)
PM-SA1000
1
SHOCK ABSORBER (EXTEND)
PM-BELT1039
1
TIMING BELT (NOT REQ'D FOR INLINE DAT)
SLIDE ASSEMBLIES
Part Number
Recommended Qty
Description
PM-AC1237 or
1
3" SLIDE ASSEMBLY
PM-AC1239 or
1
6" SLIDE ASSEMBLY
PM-AC1241
1
8" SLIDE ASSEMBLY
ROTARY ACTUATOR
Part Number
Recommended Qty
Description
PM-AC1248 1
STANDARD DUTY ROTARY ACTUATOR
NOTE: Contact Sales Department for heavy duty rotary actuator.
