Compensation Setup
The Compensation Setup menu [15] allows label placement to be adjusted for
applicator variances throughout a speed range and selection of the following options:
• Min Speed Offset: Offset value in inches, for the Label Placement at the Min
Speed Value.
• Max Speed Offset: Offset value in inches, for the Label Placement at the Max
Speed Value.
• Min Speed Value: Min Speed used for the Compensation calculation.
• Max Speed Value: Max Speed used for the Compensation calculation.
[15] Compensation Setup Menu
