Spare Parts
03/2023
SPARE PARTS
360y Core Unit Spare Parts
360y SERIES CORE UNIT SPARE PARTS LIST
WEAR ITEMS
Part Number
Recommended Qty
Description
MP-200-0235
1
NIP ROLLER LIFT CAM
PM-BELT1018
1
140XLO37 NIP TO MOTOR BELT
RECOMMENDED SPARE PARTS
Part Number
Recommended Qty
Description
ASS-200Y-0410
1
24V/5V DC POWER SUPPLY
PE-FU4002
1
2 amp CURRENT LIMITING FUSE
PE-FU4005
1
5 amp CURRENT LIMITING FUSE
PE-FU4010
2
10 amp CURRENT LIMITING FUSE
PE-FU7002
1
2 amp FAST ACTING FUSE
PE-FU7003
1
3 amp FAST ACTING FUSE
MP-200-0242 or
1
NIP DRIVE - 5" DRIVE ROLL w/ COATING
MP-200-2242 or
1
NIP DRIVE - 7.5" DRIVE ROLL w/ COATING
MP-200-5242
1
NIP DRIVE - 10" DRIVE ROLL w/ COATING
PE-SE3080
1
FIBER OPTIC LABEL SENSOR
EXTENDED SPARE PARTS
Part Number
Recommended Qty
Description
PE-SE0994-PD
1
RETRO-REFLECTIVE PRODUCT DETECT SENSOR w/ TAPE
add PE-SE3051
1
SIGNAL SWITCHING CABLE (FOR TRAILING EDGE DETECTION)
PE-CO1018
1
SELF LOCKING POWER CORD - 12 FT. LG.
MP-DR1080 or
1
YASKAWA MP 400W MOTOR DRIVE
MP-DR1082
1
YASKAWA MP 200W MOTOR DRIVE
MP-IN1013
1
APPLICATOR TOUCH SCREEN
PE-MO1099
1
NIP DRIVE YASKAWA MOTOR
PM-BE1230
1
NIP DRIVE - EW-5/8 LIFT THRUST WASHER
SAS-200-0129O
1
NIP DRIVE - OUTSIDE DRIVE ROLL SUPPORT ASSEMBLY
SAS-200-0129I
1
NIP DRIVE - INSIDE DRIVE ROLL SUPPORT ASSEMBLY
ASS-200-0130 or
1
NIP DRIVE - 5" NIP ROLLER ASSEMBLY WITH SHAFT
ASS-200-2130 or
1
NIP DRIVE - 7.5" NIP ROLLER ASSEMBLY WITH SHAFT
ASS-200-5130
1
NIP DRIVE - 10" NIP ROLLER ASSEMBLY WITH SHAFT
SAS-200-0135 or
1
5" TENSION ROLLER ASSEMBLY w/o SHAFT
SAS-200-2135 or
1
7.5" TENSION ROLLER ASSEMBLY w/o SHAFT
SAS-200-5135
1
10" TENSION ROLLER ASSEMBLY w/o SHAFT
PE-FAN1120
2
FAN GUARD
