FC 300 Design Guide
How to Program
• Counter A [60]: (Terminal 29 or 33 only) Input
for increment counting in the SLC counter.
• Counter A [61]: (Terminal 29 or 33 only) Input
for decrement counting in the SLC counter.
• Reset Counter A [62]: Input for
reset of counter A.
• Counter B [63]: (Terminal 29 or 33 only) Input
for increment counting in the SLC counter.
• Counter B [64]: (Terminal 29 or 33 only) Input
for decrement counting in the SLC counter.
• Reset Counter B [65]: Input for
reset of counter B.
5-10 Terminal 18 Di gital I npu t
Function:
Select the function from the available
digital i nput range.
5-11 Terminal 19 Di gital I npu t
Function:
Select the function from the available
digital i nput range.
5-12 Terminal 27 Di gital I npu t
Function:
Select the function from the available
digital i nput range.
5-13 Terminal 29 Di gital I npu t
Option:
*
Jog [14]
Counter A (up) [60]
Counter A (down) [61]
Counter B (up) [63]
Counter B (down) [64]
Function:
Select the function from the available digital
input range and the additional options [60],
[61], [63] and [64]. Counters are used in
Smart Logic Control functions. This parameter
is available for FC 302 only.
5-14 Terminal 32 Di gital I npu t
Option:
*
No operation [0]
Function:
Select the function from the available digital
input range. Counters are used in Smart
Logic Control functions.
5-15 Terminal 33 Digital Input
Option:
*
No operation [0]
Counter A (up) [60]
Counter A (down) [61]
Counter B (up) [63]
Counter B (down) [64]
Function:
Select the function from the available digital
input range and the addit ional options [60],
[61], [63] and [64]. Counters are used in
Smart Logic Control functions.
5-16 Terminal X30/3 Digit al Input
Option:
*No o peration [0]
Function:
This parameter is active when option module MCB
101 is installed in the adjustable frequency drive.
5-17 Terminal X30/4 Digit al Input
Option:
*No o peration [0]
Function:
This parameter is active when option module MCB
101 is installed in the adjustable frequency driv
e.
5-18 Terminal X30/4 Digit al Input
Option:
*No o peration [0]
Function:
This parameter is active when option module MCB
101 is installed in the adjustable frequency drive.
" 5-3* Digital Outputs
5-30 Termin al 27 Digital Output
Function:
Select Bus ctrl. [45] to control the output via bus.
The state of the output is set in par. 5-90. The
output state is retained in the event of bus time-out.
*
default setting ()display text []value for use in communication via serial communication port
