Danfoss iC7 Series

Table 81: Technical Data (continued)
Technical item or function Technical data
Vibration (IEC 60068-2-6)
• IEC/EN 61800-5-1 + A1
• IEC/EN 62477-1 + A1
• IACS UR E10
Testing was performed according to IEC/EN 61800-5-1 +
A1 and IEC/EN 62477-1 + A1, with these specifications:
• Frequency range 5–150 Hz
• Amplitude ±0.5 mm, 5–22.29 Hz
• Constant peak acceleration 10 m/s² (1 g
n
), 22.29–150
Hz
Testing was performed according to IACS UR E10, with
these specifications:
• Frequency range 2–100 Hz
• Amplitude ±1.0 mm, 2–13.2 Hz
• Constant peak acceleration 7 m/s² (0.7 g
n
), 13.2–100 Hz
with maximum amplification of 5
Shock (IEC 60068-2-27) Maximum 15 g, 11 ms (in package)
Noise level
(1)(1)
• IM10L, AM10L, IR10L, AR10L, IR12L, AR12L: 70 dB(A)
• DM10L, DM12L, DR10L, DR12L: max. 87 dB(A) at worst
case operation point
• 2 modules in parallel: +3 dB(A)
• 3 modules in parallel: +4.8 dB(A)
• 4 modules in parallel: +6 dB(A)
• 5 modules in parallel: +7 dB(A)
• 6 modules in parallel: +7.8 dB(A)
• 7 modules in parallel: +8.5 dB(A)
• 8 modules in parallel: +9 dB(A)
Immunity Fulfills IEC/EN 61800-3 + A1, 1st and 2nd environment
Fulfills IEC/EN 61000-6-2
EMC
Emissions 525–690 V AC: IEC/EN 61800-3 + A1, category C3, when
C3 > 100 A, if the drive is installed according to the in-
structions of the manufacturer.
All: The EMC category can be changed to C4 for IT type
mains.
DC/DC converter: C4
Grid Converter: CISPR 11 (EN 55011) Class A
220 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
