User Interface
130
DX8210 Barcode Scanner
starting with '51L' and with length 8, 9 or 12 digits
starting with '52L' and with length 8, 9 or 12 digits
starting with '54L' and with length from 6 to 19 digits
starting with '55L' and with length from 6 to 19 digits
Diagnostic Messages
Select the check boxes as needed to enable. If selected, these parameters allow
selecting the desired communication channel (Main, Aux, User Socket#n) to be
used for transmitting barcode messages coming from slaves.
The selection is available only if the desired communication channel is free (Data
TX parameter disabled).
The diagnostic data format can be defined through the commands provided by a
terminal interface.
Debug Messages
Select the check boxes as needed to enable. If selected, these parameters allow
selecting the desired communication channel (Main, Aux, User Socket#n) to be
used for transmitting debug messages coming from slaves.
The selection is available only if the desired communication channel is free (Data
TX parameter disabled).
DPD Code Filters
If DPD Code Filter is enabled, the user can select the DPD code to be transmitted by
selecting its check box. All codes different from the selected DPD will also be
transmitted.
This group allows selecting the DPD code type(s) to be transmitted. These codes
belong to the Interleaved 2/5 or Code 128 family and have one of the following
characteristics:
I2of5 Code, Length is 10
I2of5 Code, Length is 12
I2of5 Code, Starts with '0', Len“Special Host Protocol: None” on page 131gth
is 4
I2of5 Code, starts with '90',Length is 4
Code 128, Length is 28
All codes belonging to code families other than Interleaved 2/5 and Code 128 will
also be transmitted.
