Datalogic Gryphon I GD4132 User Manual

ENTER/EXIT PROGRAMMING MODE
106 Gryphon™ I GD4132/GM4102/GBT4102
Stand Mode Triggered Timeout
This feature specifies the time to remain in Trigger Single mode after the trig-
ger is pulled while in Stand Mode.
This timeout is only used when the Scan Mode is configured as Stand
Mode.
Stand Mode Triggered Timeout = 0.5 Seconds
DEFAULT
Stand Mode Triggered Timeout = 1.5 Seconds
Stand Mode Triggered Timeout = 2 Seconds
Stand Mode Triggered Timeout = 3 Seconds
Stand Mode Triggered Timeout = 4 Seconds
Stand Mode Triggered Timeout = 6 Seconds

Datalogic Gryphon I GD4132 Specifications

General

Product Name	Datalogic Gryphon I GD4132
Category	Barcode Reader
Type	Handheld
Connectivity	Wired
Interfaces Supported	USB, RS-232, Keyboard Wedge
Drop Resistance	1.5 m
Decode Capability	1D
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% (non-condensing)
Power Supply	5 VDC
Cable Length	1.8 m
Compliance	CE, FCC
