Product Reference Guide
9
Chapter 1
Introduction
About this Manual
This Product Reference Guide (PRG) is provided for users seeking advanced
technical information, including connection, programming, maintenance and
specifications. The Quick Reference Guide (QRG) and other publications associ
-
ated with this product are downloadable free of charge from the website listed
on the back cover of this manual.
Overview
Chapter 1, (this chapter) presents information about manual conventions, and
an overview of the reader, its features and operation.
Chapter 2, Setup presents information about unpacking, cable connection
information and setting up the reader.
Chapter 3, Configuration Using Barcodes provides instructions and barcode
labels for customizing your reader. There are different sections for interface
types, general features, data formatting, symbology-specific and model-spe
-
cific features.
Chapter 4, Wireless Features describes options and programming related to
radio communication features for the RF variants of the Gryphon family.
Chapter 5, References provides background information and detailed instruc-
tions for more complex programming items.
Chapter 6, Message Formatting provides details for programming options.
Appendix A, Technical Specifications lists physical and performance character-
istics, as well as environmental and regulatory specifications. It also provides
standard cable pin-outs and LED/Beeper functions.
Appendix B, Standard Defaults references common factory default settings for
reader features and options.
Appendix C, Sample Bar Codes offers sample barcodes of several common
symbologies.
Appendix D, Keypad includes numeric barcodes to be scanned for certain
parameter settings.
Appendix E, Scancode Tables lists control character emulation information for
Wedge and USB Keyboard interfaces.
