Datalogic Gryphon I GD4132

Setup
30 Gryphon™ I GD4132/GM4102/GBT 4102
Interface Selection
Upon completing the physical connection between the reader and its host, pro-
ceed to Table 1 starting on page 31 to select the interface type the reader is
connected to (for example: RS-232, Key
board Wedge, USB, etc.). Scan the
appropriate barcode in that section to configure your system’s correct inter-
face type.
Each reader model will support one of the following sets of host interfaces:
General Purpose Models Retail Point of Sale Models
•RS-232
• RS-232 OPOS
• USB
• Keyboard Wedge
•Wand Emulation
•RS-232
• RS-232 OPOS
•USB
• IBM 46XX (available with special
ca
ble)
Setting the Interface
Scan the programming barcode from this section which selects the appropriate
interface type matching the system the reader will be connected to. Next, pro-
ceed to the corresponding section in this manual (also listed in Table 1 starting
on page 31) to configure any desired settings a
nd features associated with that
interface.
Unlike some programming features and options, interface selections
require that you scan only one programming barcode label. DO NOT scan an
ENTER/EXIT barcode prior to scanning an interface selection barcode.
Some interfaces require the scanner to start in the disabled state when
powered up. If additiona
l scanner configuration is desired while in this
state, pull the trigger and hold it for five seconds. The scanner will change to
a state that allows programming with barcodes.
