RF Features
Product Reference Guide
313
BT-Only Features
BT Pin Code
This option specifies the pin code (either 4- or 16-characters) to be used for
authentication of the BT link.
To set the pin code:
1. Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Program-
ming Mode, then enable "BT
Security Mode" on page 278.
2. Specify the desired pin code length (4 or 16
) by scanning the appropriate
bar code in "Select PIN Code Length" on page 279.
3. Determine the desired characters. For example, D254 or
TOR12345678135M
4. Convert the characters to hexadecimal u
sing the ASCII Chart on the inside
back cover of this manual.
5. Go to page 279 and Scan the bar code: SET 4 CHAR
PIN CODE or SET 16-
CHAR PIN CODE.
6. Scan the appropriate alphanumeric characters from the keypad in Appen-
dix D, Keypad, representing the hexadecimal entries determined in the
steps above. You will hear a two-beep indication after the last character.
If you make a mistake before the last character, scan the CANCEL barcode
to abort and not save the entry string. You can then start again at the
beginning.
7. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit Programming
Mode.
Changing the pin code setting will unlink the devices. If the Automatic Configu-
ration Update is set to the default enabl
ed setting, the devices must only be
relinked. If the Automatic Configuration Update is set to the disabled setting,
the Pin Code setting must also be updated in the Base Station using Aladdin.
After the Base Station has been updated, the devices must be relinked.
Table 47. BT Pin Code Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
D254 STOR12345678135M
2
Convert the characters to
hexadecimal
44 32 35 34 53 54 4F 52 31 32 33 34 35 36 37 38 31 33 35 4D
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SET BT PIN CODE
5
Scan 8 or 32
Alph
anumeric Characters
From
Appendix D,
Keypad
44323534 53544F5231323334353637383133354D
6 Scan ENTER/EXIT PROGRAMMING MODE
