312 Gryphon™ I GD4132/GM4102/GBT4102
STAR Radio Protocol Timeout
This parameter sets the valid wait time before transmission between the hand-
held reader and Base Station is considered failed.
When setting this parameter, take into
consideration the radio traffic (number
of readers in the same area). The selectable range for this feature is from 02 to
25 seconds.
Follow these instructions to set this feature:
1. Determine the desired setting.
2. Pad the number with leading zeroes to
yield two digits. For example: 2 =
02, 5 = 05, 25 = 25, etc
3. Go to page 275 and scanScan the ENTER/EXIT PROGRAMMING MODE bar-
code to enter Programming Mode.
4. Scan the barcode: SELECT RADIO PROTOCOL
TIMEOUT.
5. Scan the appropriate two digits from the keypad in Appendix D, Keypad,
that represent the duration which was determined in the steps above. You
wil
l hear a two-beep indication after the last character.
If you make a mistake before the last character, scan the CANCEL bar-
code to abort and not save the entry
string. You can then start again
at the beginning.
6. Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit Programming
Mode.
This completes the procedure. See Table 46 for some examples of how to set
this feature.
Table 46. STAR Radio Protocol Timeout Examples
STEP ACTION EXAMPLES
1 Desired Setting
2 Seconds 5 Seconds 10 Seconds 25 Seconds
2 Pad with leading zero(es)
02 05 10 25
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT INTERCODE DELAY SETTING
5
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘2’ ‘0’ and ‘5’ ‘1’ and ‘0’ ‘2’ AND ‘5’
6 Scan ENTER/EXIT PROGRAMMING MODE
