Data Editing
Product Reference Guide
299
Label ID
A Label ID is a customizable code of up to three ASCII characters (each can be
one of hex 0x01-0xFF), used to identify a barcode (symbology) type. It can be
appended previous to or following the transmitted barcode data depending
upon how this option is enabled. This feature provides options for configuring
custom Label IDs as a pre-loaded set (see "Label ID: Pre-loaded Sets" below) or
individually per symbology (see "Label ID: Set Individually Per Symbology" on
page 301). If you wish to program the reader to always include an industry
standard label identifier for
ALL symbology types, see "Global AIM ID" on
page 81.
Label ID: Pre-loaded Sets
The reader supports two pre-loaded sets of Label IDs. Table 38 shows the USA
and the EU sets.
CAUTION
When changing from one Label ID set to another, all other reader con-
figuration settings, including the host interface type, will be erased
and s
et to the standard factory defaults. Any custom configuration or
custom defaults will be lost.
Table 38. Label ID Pre-loaded Sets
Symbology USA Label ID set EU Label ID set
ASCII
character
Hexidecimal
value
ASCII
character
Hexidecimal
value
ABC Codabar
S 530000 S 530000
Anker Plessey
o 6F0000 o 6F0000
CODABAR
% 250000 R 520000
Codablock F
l 6C0000 m 6D0000
CODE11
CE 434500 b 620000
CODE128
# 230000 T 540000
CODE32
A 410000 X 580000
CODE39
* 2A0000 V 560000
CODE39 CIP
Y 590000 Y 590000
CODE4
4 340000 4 340000
CODE5
j 6A0000 j 6A0000
CODE93
& 260000 U 550000
DATALOGIC 2OF5
s 730000 s 730000
EAN13
F 460000 B 420000
EAN13 P2
F 460000 L 4C0000
EAN13 P5
F 460000 M 4D0000
EAN13 P8
F 460000 # 230000
