Product Reference Guide
39
Chapter 3
Configuration Using Barcodes
This and following sections provide programming barcodes to configure your
reader by changing the default settings. For details about additional methods
of programming, see
"Configuration Methods" on page 15.
You must first enable your reader to read barcodes in order to use
this section. If you have not done this, go to
Setup, starting on
page 17
and complete the appropriate procedure.
Configuration Parameters
Once the reader is set up, you can change the default parameters to meet your
application needs. Refer to "Standard Defaults" starting on
page 363 for initial
configuration in order to set the default values and select the interface for your
a
pplication.
The following configuration parameters are applicable to all Gryphon models
covered in this manual, unless otherwise indicated. The items are divided into
logical groups, making it easy to find the desired function based on its refer-
ence group.
Interface Configuration:
• "RS-232 ONLY Interface" on page 43
• "RS-232/USB-Com Interfaces" on page 48
• "Keyboard Interface" on page 57
• "USB-OEM Interface (available with special cable)" on page 69
• "IBM 46XX Interface (AVAILABLE WITH SPECIAL CABLE)" on page 71 (avail-
able with special cable)
• "Wand Emulation Interface" on page 75
Parameters common to all interface applications:
• "Data Format" on page 79 gives options to control the messages sent to
the Host system.
• "Reading Parameters" on page 95 control various operating modes and
indicators status functioning.
