Error Codes
Product Reference Guide
321
Base Station Indications (Cordless Models ONLY)
INDICATION LEDS
Power-up Complete Yellow LED on
Reader Disabled by the HOST or the communication with
HOST i
s not established
Yellow LED blinking ~1Hz
Data/labels are transmitted to the HOST Yellow LEDs turned off for 100mSec
Programming Mode Yellow LED blinks quickly
Base and handheld ar
e exchanging data Red LED blinks quickly
Battery charging in progress Red LED on
Battery charging complete Green LED on
Battery charger error Green LED and Red LEDs bl
ink alternatively ~1Hz
No handheld is placed on the cradle Red and Green LEDs off
Base Station Button Indicators
BUTTON PUSH
EVENT
CORDLESS
YELLOW
INDICATOR
RED
INDICATOR
GREEN
INDICATOR
Push at power-up Force device connection (Aladdin) Off Off
Slow blink
Fast blink
< 1 sec (*) UV LED On/Off Off Off Off
1 to 5 sec Paging Off Off Fast blink
5 to 10 sec Unlink (Only BT) Off Off Slow blink
10 to 20 sec Reset Off Fast blink Off
> 20 sec Restore factory defaults Off Slow blink Off
(*) Only for models with UV Coun
terfeit Money Detector. See
page 12
for more details
