Setup
24 Gryphon™ I GD4132/GM4102/GBT 4102
Securing the DC Power Cord (Optional)
The DC power cord for the adapter can be secured to the bottom of the base in
order to maximize the mechanical retention of the cable itself. The routing of
the power cord can be changed to accommodate the base station positioning:
horizontal, stand or wall mounting. The cables can be looped around to the
front of the Base Station, or fed directly out the back of the Base Station, as
shown in Figure 8.
Figure 8. Options for routing the DC cord
Please refer to the arrows depicted on the bottom of the base when placing the
cables, detailed in Figure 9.
Figure 9. Arrows showing routing
