302 Gryphon™ I GD4132/GM4102/GBT4102
Table 39
STEP ACTION EXAMPLES
1. Scan the ENTER/EXIT barcode
(Scanner enters Programming Mode)
2.
Determine placement of the
La
bel ID characters BEFORE or
AFTER with regard to scanned
data using
Label ID
Control, starting on page
84
Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix
3.
Scan the barcode selecting the
sym
bology type you wish to
designate label ID characters
for using
Label ID
Symbology
Selection, starting on
page 85
.
DataBar
Omnidirectional
Code 39 Interleaved 2 of 5 Code 32
4.
Custom Label ID example
(desired cha
racters):
D B * = C 3 + P H
5.
Find hex equivalents from the
ASCII Chart (inside back
cover), then scan in these
di
gits/characters using the
barcodes in the section:
Keypad, starting on page
337
. If you make a mistake
before the last character, scan
the CAN
CEL barcode to abort
and not save the entry string.
You can then start again at the
beginning.
44 42 2A 3D 43 33 2B 50 48
6. Scan the ENTER/EXIT barcode
(Scanner exits Label ID entry)
7.
Scan the ENTER/EXIT barcode
onc
e again
(Scanner exits Programming Mode)
Result:
DB*[barcode
data]
[barcode
data]=C3
+[barcode data] [barcode data]PH
. Label ID Examples
