Customizing Configuration Settings
Product Reference Guide
37
3. Carefully lift out the gold contacts circuit, and remove the battery holder
while letting the white connector pass through the hole in the battery
holder (as shown in the picture below).
4. Remove the old battery from its place (if present), and insert the new bat-
tery in the same position.
5. Replace the battery holder and three screws,
plug in the connector, and
return the contacts circuit to its previous location.
When inserting the new battery into the handle, take care to position the
battery and the connector as shown.
6. Insert the cover in the handle and screw it back into place.
Battery replacement is now complete.
