Datalogic Gryphon Series User Manual

Enter/Exit Programming Mode Code 128
144 Gryphon™ I GD44XX / GBT4400/GM440X
Code 128 Sub-Code Exchange Transmission
Enables/disables the transmission of “Sub-Code Exchange” characters (NOT transmitted by
standard decoding).
Code 128 Quiet Zones
This feature specifies the number of quiet zones for Code 128 labels. Quiet zones are blank areas
at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the
label.
Code 128 Sub-Code Exchange Transmission = Disable
Code 128 Sub-Code Exchange Transmission = Enable
DEFAULT
$CC8SC00(CR)
$CC8SC01(CR)
Code 128 Quiet Zones = Quiet Zones on two sides
Code 128 Quiet Zones = Small Quiet Zones on two sides
$CC8LO02(CR)
$CC8LO03(CR)
DEFAULT

Datalogic Gryphon Series Specifications

General

Connectivity	USB, RS-232, Keyboard Wedge, Bluetooth
Scan Pattern	Single-line or omnidirectional
Humidity	5% to 95% non-condensing
Decode Capability	1D and 2D barcodes
Ambient Light	Up to 100, 000 lux
