Product Reference Guide
201
2D SYMBOLOGIES
2D Symbologies
The reader supports the following 2D symbologies (bar
code types). Symbology-dependent
options for each symbology are included in this chapter. See "1D Code Selection" starting on
page 109
for configuration of 1D bar codes.
2D Global Features
The following features are common to all, or in some cases, most of the available 2D
symbologies. Default settings are indicated at each feature/option with a green arrow. Also
reference Appendix B, Standard Defaults for a listing of the most widely used set of standard
factory settings. That section also provides space to record any custom settings needed or
implement
ed for your system.
To set most features:
1. Scan the ENTER/EXIT PROGRAMMING bar code at the top of
applicable program-
ming pages.
2. Scan the correct bar code to set the desired programming feature or parameter. You may
need to co
ver unused bar codes on the page, and possibly the facing page, to ensure that
the reader reads only the bar code you intend to scan.
3. If additional input parameters are needed, go to Appendix D, Keypad, and scan the
appropriate characters from the keypad.
Complete the programming sequence by scanning the
ENTER/EXIT PROGRAMMING bar
code to exit Programming Mode.
2D Global Features
• 2D Maximum Decoding Time, page 202 • 2D Normal/Inverse Symbol Control,
page 203
• 2D Structured Append, page 203
• Aztec Code, page 204 • Micro PDF417, page 219
• China Sensible Code, page 207 • QR Code, page 222
• Data Matrix, page 210 • Micro QR Code, page 225
• Maxicode, page 213 • UCC Composite, page 228
• PDF417, page 216 • Postal Code Selection, page 230
Additional information about many features can be found in the “Refer-
ences” chapter.
If you make a mistake before the last character, scan the CANCEL bar code
to
abort and not save the entry string. You can then start again at the
beginning.
