BT-Only Features
BT Pin Code
This option specifies the 4-character or 16-character pin code to be used for authentication of
the BT link. To set the pin code:
1. Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Programming
M
ode, then enable "BT Security Mode" on page 245.
2. Specify the desired pin code length (4 or 16)
by scanning the appropriate bar code in
"Select PIN Code Length" on page 246.
3. Determine the desired characte
rs. For example, D254 or STOR12345678135M
4. Convert the characters to hexadecimal using the ASCII Chart on the inside back cover of
this manual.
5. Go to page 246 and Scan the bar code: SET 4 CHAR PIN CODE or SET 16-CHAR
PIN CODE.
6. Scan the appropriate alphanumeric characters fr
om the keypad in Appendix D, Keypad,
representing the hexadecimal entries determined in the steps above. You will hear a two-
beep indication after
the last character.
7. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit Programming
Mo
de.
Table 48. BT Pin Code Setting Examples
If you make a mistake before the last character, scan the CANCEL bar code to
abort and not save the entry string. You can then start again at the beginning.
Changing the pin code setting will unlink the devices. If the Automatic Configu-
ration Update is set to the default enabled setting, the devices must only be
r
elinked. If the Automatic Configuration Update is set to the disabled setting,
the Pin Code setting must also be updated in the Base Station using Aladdin.
After the Base Station has been updated, the devices must be relinked.
STEP ACTION EXAMPLES
1 Desired Setting D254 STOR12345678135M
2
Convert the characters to
he
xadecimal
44 32 35 34 53 54 4F 52 31 32 33 34 35 36 37 38 31 33 35 4D
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SET BT PIN CODE
5
Scan 8 or 32 Alphanumeric
Character
s From
Appendix
D, Keypad
44323534 53544F5231323334353637383133354D
6 Scan ENTER/EXIT PROGRAMMING MODE
To Next Page
