Datalogic Gryphon Series User Manual

292 Gryphon™ I GD44XX / GBT4400/GM440X
Performance Characteristics
Scanning Illumination
Source
LEDs
Aiming Source
Laser Class 2
Roll (Tilt) Angle
c
Up to ± 180°
Pitch Angle
c
± 40°
Skew (Yaw) Angle
c
± 40°
Field of View
40° Hx26° V
Depth of Field (Typical)
d
Symbology
Standard Range (SR) Models
43
3, 910, BT, D
High Density (HD) Models
BT, D only
Code 39
5mil: 1.6” -7.5” (4.0 -19cm)
10mil: 0.4” - 11.8” (1.0 - 30cm)
20mil: up to 17.7” (up to 45cm)
3mil: 0.9” - 3.6” (2.4 - 9.1cm)
5 mil: 0.3” - 4.5” (0.8 -11.3cm)
EAN
7.5mil: 0.5” - 10.6” (2.0 - 27cm)
13mil: 0.6” - 15.7” (1.5 - 40cm)
7.5mil: 0” - 5” (0 - 12.7cm)
13mil: 4.3” - 6.8” (1.1- 17.2cm)
PDF 417
6.6mil: 1.0” - 5.9” (2.5 - 15cm)
10mil: 0.2” - 8.6” (0.5 - 22cm)
15mil: 0.6” - 13.4” (1.5 - 34cm)
4mil: 0.7” - 2.7” (1.8 - 6.8cm)
6.6mil: 0.1” - 4.4” (0.1 - 11.2cm)
10mil: 0” - 5.6” (0 - 14.3cm)
Data Matrix
10mil: 0.8” to 6.3” (2.0 - 16cm)
15mil: 0” to 9.3” (0 - 23.6cm)
5mil: 1.1” - 2.4” (2.8-6.1cm)
QR Code
10mil: 1.2” to 4.9” (3.0 - 12.5cm)
15mil: 0.4” to 7.5” (1.0 - 19cm)
6.7mil: 0.8” - 1.7” (2.1 - 4.2cm)
Minimum Element Width
Standard Range:
1D Minimum Resolution = 4 mil
PDF-417 Minimum Resolution = 5 mil
Data Matrix Minimum Resolution = 7 mil
High Density:
1D Minimum Resolution = 2.5 mil
PDF-417 Minimum Resolution = 4 mil
Data Matrix Minimum Resolution = 5
mil
Print Contrast Minimum
25% minimum reflectance
Item Description

Datalogic Gryphon Series Specifications

General

Connectivity	USB, RS-232, Keyboard Wedge, Bluetooth
Scan Pattern	Single-line or omnidirectional
Humidity	5% to 95% non-condensing
Decode Capability	1D and 2D barcodes
Ambient Light	Up to 100, 000 lux
