Datalogic Gryphon Series

To Next Page

To Previous Page

Reading Parameters Enter/Exit Programming Mode

Product Reference Guide

Double Read Timeout — continued

Double Read Timeout = 0.8 Second

Double Read Timeout = 0.9 Second

Double Read Timeout = 1 Second

$CSNDR50(CR)

$CSNDR5A(CR)

$CSNDR64(CR)
